4th Generation Intel Core i7-4700MQ (2.40GHz) Processor, 6MB L3 Cache
4th Generation Intel Core i7-4800MQ (2.70GHz) Processor, 6MB L3 Cache
4th Generation Intel Core i7-4900MQ (2.80GHz) Processor, 8MB L3 Cache

Core Logic

Intel© HM86 Express Chipset


Supports Dual Channel DDR3
Two 204Pin SODIMM sockets, support for DDR3 1333MHz/1600MHz (Real operation frequency depends on FSB of processor)
Expandable up to 16GB, depends on 4GB/8GB SODIMM module (32 bit OS editions have a memory limitation of 2.8GB. Other hardware or application limitations may further prevent use of all installed memory. Windows 7 64bit is required for memory configurations of 4GB and above.)


15.6" (16:9) High Definition HD (1366x768) LED-Backlit Display with Super Clear Glare Type Screen

Graphics Processor


  • 2GB GDDR5 Video RAM
  • Microsoft DirectX 11 Compatible
  • NVIDIA PhysX Technology
  • NVIDIA CUDA Technology
  • NVIDIA Optimus Technology
  • Support HDCP


One Changable 2.5" 9.5mm (H) SATA Hard Disk Drive
One mSATA Solid State Drive

Audio System

High Definition audio interface
1 Built-in Microphone
2 Built-in Speakers
THX TruStudio Pro Sound System

Pointing Device

Integrated Touchpad with Multi-gesture and Scrolling function


Multi languages isolated keyboard

I/O Ports

1 HDMI 1.4a output Port
1 RGB/VGA Port
2 USB 3.0 Ports
1 USB 2.0 Port
1 Headphone Jack
1 Microphone Jack
1 RJ-45 LAN (10/100/1000Mbps)


4-in-1 Card Reader (MMC/SD/SDHC/SDXC)


Built-in Gigabit Ethernet LAN
Integrated 802.11 ac wireless LAN + Bluetooth V4.0 + HS Combo half mini card module


Kensington Lock

Power System

1 Removable 6 cell smart Lithium-Ion battery pack 62.16Wh (optional 9 Cell Battery)
Full Range AC-in 100~240V, 50~60Hz, 90W AC Adapter, DC output 19V / 4.74A or
120W AC Adapter DC output 19V / 6.3A

OS Support

Windows 7 or Windows 8

Physical Characteristic

5.5 LBs with Battery Pack
15.1" (w) x 10" (d) x 1" (h)

Other Features

Built-in 1.3M Digital Video Camera

Optional Modules

External USB ATSC HDTV / ANALOG TV-Tuner with Remote
